Exposed tactical turrets built for dialing elevation and windage allow quick and precise bullet drop and wind drift compensation at extended ranges. When we say precise - we mean it. These turrets track better than any Bloodhound and reliably return to zero every time. A zero-reset feature lets you re-index the zero reference marks on both turrets after sight in, while fiber optic rotation indicators integrated into the turrets provide a visual cue of your turret’s position.


| Magnification: | 4-12x |
| Objective Lens Diameter: | 40 mm |
| Focal Plane: | Second Focal Plane |
| Reticle: | VMR-1 (MOA) |
| Turret Style: | Tactical |
| Tube Size: | 25.4 mm |
| Adjustment Graduation: | 1/4 MOA |
| Parallax Setting: | 91.44m |
| Max Windage Adjustment: | 70 MOA |
| Max Elevation Adjustment: | 70 MOA |
| Travel Per Rotation: | 12 MOA |
| Field of View: | 7.19m-2.4m @ 91.44m |
| Eye Relief: | 99.06mm (3.9") |
| Length: | 357.63mm (14.08") |
| Weight: | 0.50kg (17.5 oz) |


| Lengths | Heights | |||||||
|---|---|---|---|---|---|---|---|---|
| L1 | L2 | L3 | L4 | L5 | L6 | H1 | H2 | |
| 357.63mm | 48.26mm | 54.61mm | 134.62mm | 134.62mm | 87.12mm | 47.24mm | 43.43mm | |
| Aluminum Grade: | Aircraft | |
| Multi-Coated: | Fully Multi-Coated | |
| HD Lens Elements: | XD™ | |
| Shockproof: | Rugged construction withstands recoil and impact. | |
Designed to maximize long distance shooting and ranging abilities, the VMR-1 MOA reticle can be used to effectively determine ranges, holdovers, windage corrections and moving target leads.
Subtension detail for the Diamondback Tactical 4-12x40 riflescope with VMR-1 reticle.




Legendary performance and extreme durability with a tactical twist.
